Fluke 922 Airflow Meter/Micromanometer Air Pressure Velocity Volume Temperature
Fluke 922 Airflow Meter/Micromanometer Air Pressure Velocity Volume Temperature
Regular price
$379.99 USD
Regular price
$400.00 USD
Sale price
$379.99 USD
Unit price
/
per
Free Shipping
No Extra Costs
Local Warehouse
Shipping from US
Easy Returns
No Return Cost
Couldn't load pickup availability
The Fluke 922 Airflow Meter/Micromanometer is a compact HVAC diagnostic tool for measuring differential pressure, air velocity, airflow volume, and temperature in one handheld meter. It is designed for ventilation troubleshooting, duct traversals, pressure-drop testing, and indoor air quality work.
Key features
- Measures differential and static pressure, air velocity, airflow, and temperature
- Designed for HVAC airflow diagnostics and duct traversals
- User-defined duct shape and size for airflow calculations
- Resolution down to 0.001 inH2O
- 99-point data storage capacity
- Min/Max/Average/Hold functions for field analysis
- Bright backlit display and rugged handheld design
- Powered by four AA batteries
Spec
| Model | Fluke 922 |
| Product type | Airflow Meter / Micromanometer |
| Air pressure range | ±4000 Pa / ±16 inH2O / ±400 mmH2O / ±40 mbar / ±0.6 psi |
| Pressure resolution | Down to 1 Pa / 0.001 inH2O / 0.1 mmH2O / 0.01 mbar / 0.0001 psi |
| Pressure accuracy | ±1% + 1 Pa |
| Air velocity range | 250 to 16,000 fpm / 1 to 80 m/s |
| Air velocity accuracy | ±2.5% of reading at 2000 fpm (10.00 m/s) |
| Airflow volume range | 0 to 99,999 cfm / m3/hr / l/s |
| Temperature range | 0°C to 50°C / 32°F to 122°F |
| Temperature resolution | 0.1°C / 0.1°F |
| Data storage | 99 readings |
| Power | Four AA batteries |
| Battery life | Up to 280 hours without backlight, 60 hours with backlight |
| IP rating | IP40 |
Applications
- Measure pressure drops across HVAC equipment
- Verify air velocity and airflow in ducts
- Monitor indoor versus outdoor pressure relationships
- Support indoor comfort and air quality diagnostics
